03600
ALU 6061, 16“, 18", 20"
Suntour XCT, HLO
Shimano ST-EF51A-8sp.
Shimano Acera RDM3000
Shimano TY 700
Shimano HG 200/8, 12-32
Shimano FCTY501, 42/34/24T
Shimano BRTX805 mechanical
ZX Lite 584x19, double wall, 32H
WTB Nano 2.1 Comp White Stripes
Joytech, alloy, 6 bolt, 32H
Neco integrated
VP 992A
KMC Z7/110L
CTM XC Stem, 90/31,8
CTM RB K64,640/31,8
Neco integrated
CTM 9009
CTM SP 01, 350x31,6
24 speed
14.3 kg
| 16" | 18" | 20" | |
| A | 70° | 70° | 70° |
| B | 73° | 73° | 73° |
| C | 562mm | 573mm | 591mm |
| D | 406mm | 457mm | 508mm |
| E | 430mm | 430mm | 430mm |
| F | 1075mm | 1084mm | 1099mm |
| G | 120mm | 120mm | 120mm |
| H | -51,5mm | -51,5mm | -51,5mm |
| I | 470mm | 470mm | 470mm |
| J | 40mm | 40mm | 40mm |
