03606
ALU 6061, 16", 18", 20"
Rock Shox RECON, SA, TPR, 15mm, 130mm
Sram X5 / 10sp
Sram RD X7
Sram FD GX 2x10
Shimano HG 50/10, 11-36
Suntour XCM AX-D, 30-22
Shimano M396, F180/R160
ZX Lite 584x19, double wall, 32H
WTB Trail Boss 27,5"x2,25 Comp
Shimano HBM618-15mm/FHM615
Suntour XCM
HT-PA01A
Shimano HG54/112L
CTM DJ Stem, 70/31,8
CTM RB K76,760/31,8
Neco integrated
WTB Volt
CTM SP 01, 350x31,6
20 speed
13,2 kg
| 16" | 18" | 20" | |
| A | 68° | 68° | 68° |
| B | 73° | 73° | 73° |
| C | 553mm | 561mm | 565mm |
| D | 406mm | 457mm | 508mm |
| E | 430mm | 430mm | 430mm |
| F | 1083mm | 1096mm | 1110mm |
| G | 105mm | 115mm | 130mm |
| H | -48mm | -48mm | -48mm |
| I | 505mm | 505mm | 505mm |
| J | 38mm | 38mm | 38mm |
